COMPACT EXCAVATORS
TOROS TE 25
The Toros T25 Excavator represents real value for money compact earthmoving technology. Engineered for peak performance and unparalleled durability, it features a heavy-duty chassis and advanced hydraulic systems with a Nachi piston pump and an Eaton swing motor. Whether you are navigating narrow urban job sites or demanding landscaping projects, the T25 delivers the breakout force and precision required to get the job done efficiently and reliably.
Engine
Engine Rated Power
Operating Weight
Machine Control
Bucket Hitch
Pump Type
Oil Flow
Hydraulic Oil Tank Capacity
Fuel Tank Capacity
Track Type
Kubota D1105
14.2 kW
2500 KG
Pilot Joysticks
Hydraulic Hitch
Piston
34 L / min
22.5 L
28 L
Rubber
Technical Parameters
Operating Parameters
Maximum Digging Radius
Maximum Digging Depth
Max. Vertical Digging Depth
Maximum Dumping Height
Minimum Swing Radius
Blade Lifting Height
Blade Digging Depth
Maximum Digging Force
Travelling Speed
Bucket Capacity
4150 mm
2430 mm
2030 mm
2500 mm
1730 mm
268 mm
200 mm
18.4 kn
Dual 2 /4 km/h
0.04 m3
Machine Height
Max Machine Length
Chassis Width
Ground Clearance
Track Length
Track Width
Width - Track Retracted
Width - Track Extended
Boom Slew - Right
Boom Slew - Left
2210 mm
3760 mm
1300 mm
460 mm
2300 mm
250 mm
1300 mm
1445 mm
65 degrees
58 degrees
Key Dimensions
All data supplied by the manufacturer
